4. Control panel (MTR−DCI−...−H2IO)
4−14
Festo P.BE−MTR−DCI−IO−EN en 0606b
[Position set] Teach mode for programming the position set table.
[Position set]
Param. Description
[Position nr] no. Number of the position set [0...14]
[Pos set mode] [absolute/
relative]
Positioning mode
absolute = absolute position
specification, related to the project
zero point
relative = relative position
specification, related to the current
position
[Position] x
t
Target position in the selected
measuring system e.g. [mm]
[Velocity] v Positioning speed in the selected
measuring system e.g. [mm/s]
[Save...] Save parameter in EEPROM
Please note
The set parameters become effective immediately after
confirmation with OK <Enter>. The settings are saved per
manently in EEPROM with the menu command [Save...]:
· Save the parameter settings with [Save]. Only then will
the settings be retained even if the power supply is
switched off or if there is a power failure.
