FiberHome AN5506-04-FS User Manual

4
Web Configuration Guide
Figure
4.30 Route QoS Configuration
2
. Configure the parameters relevant to QoS according to the
requirement. Table 4.17 describes the parameters.
3. Click Apply to save and apply the configuration.
T
able 4.17 Parameters of Route QoS Configuration
Item Description
Type Select the priority type.
Priority
Sets the priority value. The DSCP priority value ranges
from 0 to 63; the 802.1p priority value ranges from 0 to 7.
Protocol
The protocol types include ALL, TCP and UDP.
Source IP Source IP address.
Source Port
Source port.
Target IP
The destination IP address.
Target Port The destination port.
Enable Enables or disables the QoS rule.
105

FiberHome AN5506-04-FS Specifications

General

Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	2.4 GHz
PON Interface	GPON
Ports	4 x 10/100/1000 Mbps Ethernet, 2 x POTS
