FIBOCOM MC610 Series Hardware Guide 12/70
characteristics
Dimensions: 24.2 × 26.2 × 2.1 mm
Weight: about 2 g.
Interfacing
Antenna
Antenna: main set ×1, WIFI_SCAN/BT ×1
Functional
interface
USIM3.0V/1.8V ×2
USB2.0 × 1
System state indicator
ADCx4, UARTx3, I2C, SPI, KEY, SPK, MIC, HEADMIC, HP
Software
Protocol stack
Embedded TCP/IP and UDP/IP protocol stack
AT command
3GPP TS 27.007 and 27.005, and proprietary FIBOCOM AT
Firmware update
USB
Voice service
HR, FR, EFR, AMR, caller display, call transfer, call holding, call waiting, multi-party
call, etc.
SMS business
Point-to-point MO, MT, cell broadcast, support Text and PDU mode
When the temperature exceeds the normal operating temperature range of -30°C to +75°C, the RF
performance of the module may slightly exceed the 3GPP specification.
2.3 Hardware Diagram
Figure 2-1 shows the main hardware functions of MC610 series modules, including baseband and RF
functions.
The baseband section contains:
l LTE FDD controller
l PMIC
l UART, SIM, I2C, SPI, ADC, KEY, SPK, MIC, HEADMIC and HP
The RF part includes:
Note:
