FIBOCOM MC610 Series Hardware Guide 56/70
Table 4-4 Antenna index
Main Antenna Requirements of MC610 Series Module
Frequency range
The most suitable antenna must be used to fit the relevant bands
Bandwidth
(GSM/GPRS)
GSM850: 70 MHz
GSM900: 80 MHz
GSM1800(DCS): 170 MHz
GSM1900(PCS): 140 MHz
Bandwidth (LTE)
LTE band 1(2100): 250 MHz
LTE Band 2(1900): 140 MHz
LTE Band 3(1800): 170 MHz
LTE Band 4(2100): 145 MHz
LTE Band 5(850): 70 MHz
LTE Band 7(2500): 190 MHz
LTE Band 8(900): 80 MHz
LTE Band 28(800): 100 MHz
LTE Band 66(2100): 470 MHz
Impedance
50Ω
Input power
> 33 dbm (2 W) peak power GSM
> 23 dbm average power LTE
Standing wave ratio
recommendation
≤ 2:1
4.7 BT&WIFI_ SCAN External Design
There is no integrated WiFi filter in the module mc610. When WiFi function is required, filter design should
be added externally. Refer to the following figure:
