FIBOCOM MC610 Series Hardware Guide 52/70
Band 66
-98
10MHz Band width
4.4 WIFI/BT
MC610 series products support WIFI and BT function except MC610-LA-00, please refer chapter 2.1.
They share one channel antenna ANT_WIFI, WIFI only support WIFI-SCAN.
WIFI/BT receiving sensitivity is shown in the following table:
Function
Mode
Rx Sensitivity (dBm)
Note
WIFI
11b
-90
PER<8%
BT
BLE
-91
PER<30.8%
BT Transmit Power is shown in the following table:
Function
Mode
Tx Power (dBm)
Note
BT
BLE
6±3
-DC power supply=3.8V
BT Power Consumption is shown in the following table:
Function
Mode
Power Consumption (mA)
Note
BT
BLE
75
-DC power supply=3.8V
Note
：
It is recommended to add a TVS (recommended model: ESD9D5U-2/TR) to improve the
anti-surge capability of the product.
4.5 RF PCB Design
4.5.1 Antenna RF Connector
The antenna of the MC610 series modules is led from bonding pads. It is recommended that customers
use the U.FL-R-SMT-1 antenna connector and use the matching RF adapter lines.
