Fibocom MC610 Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FIBOCOM MC610 Series Hardware Guide 42/70
3.7 Status Indication
3.7.1 LPG Signal
MC610 series modules provide an interface of network indicator output signal.
Table 3-15 LPG pin
Pin Name
I/O
Pin
Description
LPG
O
38
Module status indication
Description of LPG status of MC610 series module network indicator.
Table 3-16 LPG status
Mode
LPG
Description
1
Quick flash (600 ms High/600 ms Low)
No SIM card
SIM PIN
Being registered (T<15 S)
Registration failure
2
Slow flash (75 ms Low/3,000 ms High)
Standby
3
Fast flash (75 ms Low/75 ms High)
Data link establishment
4
High
Sleep
5
Low
Voice call
The reference circuit of network indicator interface of MC610 series modules is shown in the following
figure:
