4 RF Interface
51
4 RF Interface
4.1 RF Indicators
Table 31. RF indicators
Indicator
Description
LTE system
Operating band
LTE FDD: B1/2/3/4/5/7/8/20/28/66
Modulation
Uplink: QPSK/16QAM
Downlink: QPSK/16QAM/64QAM
Transmitting
power
23±2dBm
Peak rate
LTE FDD: 10.296Mbps DL/5.160Mbps UL (Cat 1)
Table 32. Transmitting power of each band
System
Band
Tx Power (dBm)
Description
LTE FDD
Band 1
23±2
10MHz Bandwidth, 1 RB
Band 2
23±2
10MHz Bandwidth, 1 RB
Band 3
23±2
10MHz Bandwidth, 1 RB
Band 4
23±2
10MHz Bandwidth, 1 RB
Band 5
23±2
10MHz Bandwidth, 1 RB
Band 7
23±2
10MHz Bandwidth, 1 RB
Band 8
23±2
10MHz Bandwidth, 1 RB
Band 20
23±2
10MHz Bandwidth, 1 RB
Band 28
23±2
10MHz Bandwidth, 1 RB
Band 66
23±2
10MHz Bandwidth, 1 RB
