7 Structure Specifications
68
Figure 34. Bottom schematic diagram
7.2 Dimensions
Table 38. Packaging mode
Indicator
Description
Weight
1.2g
Package
LGA, with 109 pins in total
Appearance dimensions
(17.7±0.15) mm × (15.8±0.15) mm × (2.4±0.2) mm
Structure dimensions
See the following figure.
The following figure shows the structural dimensions.
