4 RF Interface
53
Parameter
Average
Current (mA)
LTE FDD
Paging cycle #128 frames (remove USB)
1.5
LTE FDD
Paging cycle #128 frames (USB suspend)
2.2
LTE FDD
Paging cycle #256 frames (remove USB)
1.2
LTE FDD
Paging cycle #256 frames (USB suspend)
1.9
I
IDLE
LTE FDD
Paging cycle #64 frames (USB in place)
25
LTE FDD
Paging cycle #64 frames (remove USB)
11
I
LTE-RMS
LTE FDD
LTE FDD Data transfer Band 1 @+23.5dBm
660
LTE FDD
LTE FDD Data transfer Band 2 @+23.5dBm
660
LTE FDD
LTE FDD Data transfer Band 3 @+23.5dBm
630
LTE FDD
LTE FDD Data transfer Band 4 @+23.5dBm
630
LTE FDD
LTE FDD Data transfer Band 5 @+23.5dBm
600
LTE FDD
LTE FDD Data transfer Band 7 @+23.5dBm
650
LTE FDD
LTE FDD Data transfer Band 8 @+23.5dBm
600
LTE FDD
LTE FDD Data transfer Band 20 @+23dBm
550
LTE FDD
LTE FDD Data transfer Band 28 @+23dBm
620
LTE FDD
LTE FDD Data transfer Band 66 @+23dBm
630
The above power consumption data is the measured average value, and the
floating range within 10% is normal.
