dielectric constant, and impedance as applicable for each type of antenna);
b) Each design shall be considered a different type (e.g., antenna length in multiple(s) of
frequency,
the wavelength, and antenna shape (traces in phase) can affect antenna gain and must be
considered);
c) The parameters shall be provided in a manner permitting host manufacturers to design the
printed circuit (PC) board layout;
d) Appropriate parts by manufacturer and specifications;
e) Test procedures for design verification; and
f) Production test procedures for ensuring compliance.
The module grantee shall provide a notice that any deviation(s) from the defined parameters
of the antenna trace, as described by the instructions, require that the host product
manufacturer must notify the module grantee that they wish to change the antenna trace
design. In this case, a Class II permissive change application is required to be filed by the
grantee, or the host manufacturer can take responsibility through the change in FCC ID (new
application) procedure followed by a Class II permissive change application.
Explanation: Yes, The module with trace antenna designs, and This manual has been shown
the layout
of trace design, antenna, connectors, and isolation requirements.
2.6 RF exposure considerations
It is essential for module grantees to clearly and explicitly state the RF exposure conditions
that permit a host product manufacturer to use the module. Two types of instructions are
required for RF exposure information: (1) to the host product manufacturer, to define the
application conditions (mobile, portable – xx cm from a person’s body); and (2) additional text
