"AUTO"
Vacuum can be switched over from the placement head
(20) to the pipette (24) by pressing the pipette slightly
on the body of the component to catch it
"EXT"
Vacuum can be switched by an additional switch, e.g. a
foot switch, connected to socket (65)
50
x micrometer screw
Acts as a handle to position x-y positioning table (29)
during x-y coarse- and Θ fine alignment; used for fine
positioning in x axis during final alignment
51
y micrometer screw
Acts as a handle to position x-y positioning table (29)
during x-y coarse- and Θ fine alignment; used for fine
positioning in y axis during final alignment
51a
Z micrometer screw
see 2.2
Height adjust for the positioning table; used for fine
adapting the working level
54
Vacuum status
Indicates the vacuum status of the head and pipette.
See 3.4.3
55
VACS off
Switch to turn on/off the Vacuum Control Safety System,
see 3.4.4
57
Mains Power pushbutton
Applies primary AC power to Placer Control Box (39) and
optional modules connected to (62 e), by power relay
(max. 10 A at 230V, 15 A at 115 V ). Can't be switched
OFF if the pivot arm (27) is upright and a component is
in the placement head
58
Power ON indicator
When 'ON', indicates that the DC supply for the
electronics in the Placer Control Box (39) is active
59
Magnification changer
Switches/zooms magnification of the FoV (18).
61
Vacuum pipette socket
Connects vacuum and pipette switch signal from Placer
Control Box (39) to vacuum pipette (24).
62 a
Mains fuse for Placer Control Box
Opens when excess voltage occurs in the Placer Control
Box (39) circuitry.
62 e
Aux. power female connector
Supplies mains voltage to video monitor and other
optional modules via switch (57) and power relay
62 f
Mains male connector
Connects Placer Control Box (39) to power inlet cord.
65
Vacuum foot switch connector
Connects foot switch to Placer Control Box
66
Arm assembly socket
For plug (28) from pivot arm (27)
68
Camera connector socket:
CAMERA I, yellow
Supplies 12 V DC to optional video module, e.g. FV2,
switched on when the arm is raised, connect with the
yellow marked plug
69
Camera connector socket:
CAMERA II, blue
Supplies 12 V DC to optional video module, e.g. FW1,
switched on when the arm is lowered, connect with the
blue marked plug
69a
Option output
Permanent 12 V DC outlet for optional devices, e.g.
additional camera
70
Base plate
Supports major assemblies
71
Support arm
Supports VAS (18), beam splitter, lighting and other
vision options
72
Upper arm position (UAP)
adjustment, see 4.2.2
Adjusts upper arm position, important for positioning
accuracy of pivot arm (27)
87
Air cushion hose
Compressed air supply for positioning table from Placer
Control Box via support arm
89
Lower Arm Position (LAP) lever
Allows the pivot arm (27) to be moved carefully for
exact placement
