6. Adjusting the Beam Splitter
Reproduce the placement error as seen on the screen shot by using the Allen key.
This compensates the offset / placement error at hand.
Adjust the x offset
Adjust the y offset
Adjust the nonius overlay again with the y-x-micrometer screws
