3. Technical information, E5/E6/E8
Performance
Ram force 200 kN / optional 300 kN (later upgrading is possible)
Punching stroke electrical servo motor
Tool stations in the turret 20
Tools Thick Turret
Max. punch diameter 89 mm
Clamps, pneumatic 2 pcs / optional 3 pcs (E5) 3 pcs / optional 4 pcs (E6/
E8)
Turret rotation 23.8 r/min (E5) 30 r/min (E6/E8)
Tool change time
(1)
1–3 s
Auto-index system:
• Index tool stations standard 2 pcs / max. 10 pcs
• Max. punch diameter 89 mm
• Max. tool rotation 166 r/min
Indexable upforming system (option):
• Upforming force 200 kN
• Die stroke height in forming programmable by increments of 0.001 mm (max. 12
mm; NC axis)
• Upforming speed with 25 mm form-to-
form distance
(2)
80–150 1/min
E5 E6/E8
X-traverse 2584 mm 3144 mm
Max. X-traverse, axis speed 90 m/min 120 m/min
Y-traverse 1317 mm 1615 mm
Max. Y-traverse, axis speed 60 m/min 90 m/min
Max. positioning speed 108 m/min 150 m/min
Max. hit speed
(3)
:
E5 E6/E8
• 1 mm between holes
• 25 mm between holes
• 250 mm between holes
800 1/min
430 1/min
160 1/min
900 1/min
-
-
Punching accuracy according to LKP-7100
(4)
:
• Max. hole location deviation (X/Y axis) 0.1 mm
• Max. hole-to-hole distance deviation (X/Y
axis)
+/- 0.05 mm
• Max. angular deviation (CNC Index Tool) +/- 0.1°
Positioning accuracy according to VDI/DGQ 3441
(5)
:
• Positional deviation, Pa (X/Y axis) 0.08 mm (+/- 0.04 mm)
• Positional scatter, Ps (X/Y axis) 0.04 mm (+/- 0.02 mm)
Sheet dimensions
Max. sheet size X x Y 2530 mm x 1270 mm (E5) 3074 mm x 1565 mm (E6)
4300 mm x 1565 mm (E8)
Max. sheet weight
(6)
200 kg
