9. Additional clamp (option)
All turret punch presses have connectors for the installation of an additional clamp. To install the
additional clamp, connect the pneumatic coupling and push the clamp into its place on the guide. The
central locking of the clamps must be open for attachment of the clamp to the guide.
• Remove coupling 1_3J153.3 when installing the third clamp in
its place. Attach coupling 1_3J153.3 when removing the third
clamp.
• Remove coupling 1_3J153.4 when installing the fourth clamp in
its place. Attach coupling 1_3J153.4 when removing the fourth
clamp.
