Finn-Power E5x - Weekly Maintenance Tasks for E5;E6;E8 Machines

7.1. E5 maintenance points
5
2434
16
6
Figure: E5 maintenance points
7.2. E5/E6/E8 weekly maintenance
Point E5/E6/E8 Lubrication
• Clean the brush tables with a vacuum cleaner.
• Clean the X and Y linear guides.
• Clean the impurities from around the X and Y linear guides
and ball screws.
Check the compressed air feed pressure.
Check the functioning of the drain valve in the service unit’s
water separator.
• Clean the valve and filter bowl if necessary.
• The water separator is equipped with an automatic draining
system.
User Guide - E5 Turret Punch Press
37 (46)
