Finn T75 HydroSeeder - Suction, Discharge, and Recirculation

T75 MN0929
39
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
SUCTION, DISCHARGE AND RECIRCULATION PIPING
Ref.
No. Part Number Description No. Req’d
1 080713 * Clump Assembly 1
2 080366 3 in. Pipe Clamp 3
002439 3 in. Clamp Gasket 1 per
3 002868 90° Grooved Elbow 1
4 080732 Suction Line Valve Assembly 1
004737 Suction Line Shutoff Valve 1 per
080698 Suction Pipe Elbow Weldment 1 per
080666-04 Short Suction Pipe Stub 1 per
5 008469 Discharge Flange Gasket 1
6 080718 Discharge Flange Pipe 1
7 005083-07 Recirculation Nozzle 1
8 005156 1 in. Pipe Clamp 2
005183 1 in. Clamp Gasket 1 per
9 005083-08 Recirculation Nozzle 1
10 021559 1 in. Ball Valve 1
11 080650 Recirculation Hose 1
12 006250 2 in. Pipe Clamp 3
006251 2 in. Clamp Gasket 1 per
13 080720 Intermediate Pipe 1
14 080719 Platform Pipe 1
15 007710 1-1/2 in. Ball Valve 1
16 003243 1-1/2 in. Aluminum Pipe Nipple 1
17 080377 1-1/2 in. Female Coupler 1
006515 1-1/2 in. Coupler Gasket 1
KITS AND MARKERS
* When ordered: the Clump Assembly (Finn P/N: 080713) includes Pipe Clamps. [Quantity 2
(Part Number: 080366)] and a 90° Grooved Elbow [Quantity of 1 (Part Number: 002868)].
