T75 MN0929
47
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
* NOTE: On the T75 unit, the quantity of part # X0828SS is a total of 8 per unit, except for the
T75 Skid, which replaces two of this part with part # X0840SS.
The two replacement bolts are used for the lower two bolts on the front of the unit to
hold the agitator shaft toe guard.
BEARING / AGITATOR ASSEMBLY
Ref. Kit
No. Ref. Part Number Description No. Req’d
1 Y08SS Agitator Nut 4 per
2 012605 Bevel Sealing Washer 4 per
3 007705 Grease Fitting 1 per
4 007211 Flangette with Lube Coupling 1 per
008154 Male to Female Adapter 1
5 003022 Bearing 1 per
6 007212 Flangette with Groove 1 per
7 006975 Agitator Bearing Gasket 1 per
8 007416 Agitator Rotary Gasket 1 per
9 007417 Clamping Ring 1 per
10 X0828SS Agitator Bolt 4 per*
11 F60-0011-01 Rear Bolt-On Paddle with I.D. Hole 2
12 005081-02 Agitator Drive Stub Shaft 1
13 080661 Main Agitator Section with Paddles 1
14 080723 Agitator Extension 1
15 F60-0011-02 Bolt-On Paddle without I.D. Hole 3
KITS AND MARKERS
007420 Bearing and Seal Assembly (Includes Items 1 – 10)
