T75 MN0929
49
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
DISCHARGE BOOM
Ref. Kit
No. Ref. Part Number Description No. Req’d
1 005734 Boom Weldment 1
2 Z0632SCP Square Head Set Screw - 3/8 - 16 x 2 in. Long 1
3 080559-01 Boom Handle 1
4 007286 Discharge Balance Torsion Spring 1
5 005528-03 Adjusting Collar 1
6 Z0616SCP 3/8 - 16 x 1 in. Long Square Head Set Screw 2
7 00Y06J 3/8 - 16 Jam Nut 1
8 007288 2 in. x 90° Swivel Joint 1
9 080734 Boom Stand Pipe 1
10 006102 2 in. Female Nyglass Coupler 1
006514 2 in. Coupler Gasket 1
11 012287 2 in. Ball Valve 1
12 006483 Adapter Pipe 1
NOT SHOWN
005931 Boom Handle Protective Cap 1
005528-02 Boom Hold Down 1
031245 Hold Down Pin 1
KITS AND MARKERS
080716 Discharge Boom Assembly
006969 Swivel Repair Kit (2 Required)
