Program Mode
26
411 Communicator Document #50921 Rev. E 12/09/2008 P/N 50921:E
Once in Program Mode, the digital communicator will:
 Activate relay which is defaulted to DACT trouble
 Ignore all other keys other than those mentioned in this section
 Display 00_F on the Programmer display
 Continue to communicate any events not previously acknowledged at a central station prior to entering
Programming Mode
While in Program Mode, the first three locations on the left of the Programmer display represent the memory address
and the last location (farthest right) represents the contents of the memory address. The first address displayed is
shown below:
When desired changes have been completed, exit Programming Mode by pressing the MODE key, followed by the
4-digit code for an alternate mode and then the [ENTER/STORE] key. During Program Mode, if no key is pressed
within 10 minutes, the communicator will revert to Normal Mode.
The Programmer cable should not be removed from the 411 unless the communicator is in Normal Mode. If the Pro-
grammer cable is removed while the 411 is in a Mode other than Normal Mode, the communicator will automatically
revert to Normal Mode following a 10 minute
time-out period. Note that if the Programmer is in Troubleshoot Mode
when the cable is removed, the 411 will revert to Normal Mode following a 20 minute
time-out period.
3.3.1 DACT Programming
Primary Central Station Phone Number (00 - 19)
The first twenty addresses (00 - 19) are factory set to 'F' (00_F to 19_F). Programming is done as follows:
 If your phone number is 484-7161, press 4.
 The display will read 00_4.
 Press [ENTER/STORE] to save the entry to memory and increment to the next address 01_F.
 Enter the remaining numbers in their respective addresses as shown below:
Valid entries for both the primary and secondary phone numbers are 0 to 9 and A to F with the numeric digits as
dialed numbers and the hexadecimal digits representing the following functions:
• A = * on a Touch-Tone phone keypad
• B = # on a Touch-Tone phone keypad
• C = look for secondary dial tone for up to two seconds (then dial anyway)
• D = three second pause
• E = five second pause
• F = end of phone number (Note: F must remain in all unused phone number addresses)
New FCC regulations allow extra digits to the carrier ID code, to identify the long distance carrier. The expanded
phone number field of 20 digits facilitates this function. Simply enter the digits required by the telephone company if
desired.
00_F
(address)
(data)
4 8 4 7 1 6 1 F F F F F F F F F F F F F
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19
Entry
Address
