Fire-Lite 411 - Program Mode: Event Codes - Primary

Program Mode
28
411 Communicator Document #50921 Rev. E 12/09/2008 P/N 50921:E
Ademco Contact ID Format Primary Central Station Event Codes
If 'E' is entered for address 20, the following data is automatically programmed for the Primary Central Station
phone number event codes. Enter '000' for the Setting to disable the report to the Central Station. The Channel #
is not programmable.
4+2 Standard and 4+2 Express Formats Primary Central Station Event Codes
If 1, A or C is entered for address 20, the following data is automatically programmed for the Primary Central Sta-
tion phone number event codes. Enter '00' for the Setting to disable the report to the Central Station.
TABLE 3-1: Ademco Contact ID Format - Primary
Address Description Setting
Channel/
Input #
138 - 140 Primary # Input Channel 1 Active Event Code 110 001
141 - 143 Primary # Input Channel 2 Active Event Code 373 002
144 - 146 Primary # Input Channel 3 Active Event Code 200 003
147 - 149 not used
150 - 152 Primary # Input Channel 1 Fault Event Code 380 001
153 - 155 Primary # Input Channel 2 Fault Event Code 380 002
156 - 158 Primary # Input Channel 3 Fault Event Code 380 003
159 - 161 not used
162 - 164 Primary # Phone Line 1 Voltage Fault Event Code 351 000
165 - 167 Primary # Phone Line 2 Voltage Fault Event Code 352 000
168 - 170 Primary # Phone Number 1 Comm. Fault Event Code 354 001
171 - 173 Primary # Phone Number 2 Comm. Fault Event Code 354 002
174 - 176 Primary # System Off Normal Fault Code 308 000
177 - 179 Primary # System Test Message 602 000
180 - 182 Primary # System Abnormal Test Message 608 000
183 - 185 not used
186 - 188 not used
189 - 191 not used
192 - 194 not used
TABLE 3-2: 4+2 Standard and 4+2 Express Formats - Primary
Address Description Setting
138 - 139 Primary # Input Channel 1 Active Event Code 11
140 - 141 Primary # Input Channel 2 Active Event Code FF
142 - 143 Primary # Input Channel 3 Active Event Code 83
144 - 145 not used
146 - 147 Primary # Input Channel 1 Fault Event Code F1
148 - 149 Primary # Input Channel 2 Fault Event Code F2
150 - 151 Primary # Input Channel 3 Fault Event Code F3
152 - 153 not used
154 - 155 Primary # Phone Line 1 Voltage Fault Event Code 64
156 - 157 Primary # Phone Line 2 Voltage Fault Event Code 65
158 - 159 Primary # Phone Number 1 Comm. Fault Event Code 6A
160 - 161 Primary # Phone Number 2 Comm. Fault Event Code 6B
162 - 163 Primary # System Off Normal Fault Code 6F
164 - 165 Primary # Input Channel 1 Active Restoral Code E1
166 - 167 Primary # Input Channel 2 Active Restoral Code E2
168 - 169 Primary # Input Channel 3 Active Restoral Code E3
170 - 171 not used
172 - 173 Primary # Input Channel 1 Fault Restoral Code D1
174 - 175 Primary # Input Channel 2 Fault Restoral Code D2
176 - 177 Primary # Input Channel 3 Fault Restoral Code D3
178 - 179 not used
180 - 181 Primary # Phone Line 1 Restoral Code A4
182 - 183 Primary # Phone Line 2 Restoral Code A5
184 - 185 Primary # Phone Number 1 Restoral Code AA
186 - 187 Primary # Phone Number 2 Restoral Code AB
188 - 189 Primary # System Off Normal Restoral Code AF
