411 Communicator Document #50921 Rev. E 12/09/2008 P/N 50921:E 29
Program Mode
All 3+1, 4+1 and 4+2 Expanded Formats Primary Central Station Event Codes
If 0, 2, 3, 4, 5, 6, 7, 8 ,9, B or D is entered for address 20, the following data is automatically programmed for the
Primary Central Station phone number event codes. Enter '0' for the Setting to disable the report to the Central
Station.
Primary Central Station Number Account Code (21 - 24)
The four locations at addresses 21 - 24 default to all '0's. Valid entries are 0 - 9 and A - F. The number of digits
entered must match the format selection. If programming '2, 3, 4 or 5' into address 20, enter three digits (one digit
each in locations 21, 22 and 23 - location 24 is ignored). If programming '0, 1, 6, 7, 8, 9, A, B, C, D or E' into
address 20, enter four digits (one each in locations 21, 22, 23 and 24).
190 - 191 Primary # System Test Message 99
192 - 193 Primary # System Abnormal Test Message 91
194 - 195 not used
196 - 197 not used
198 - 199 not used
200 - 201 not used
TABLE 3-3: All 3+1, 4+1 and 4+2 Expanded Formats - Primary
Address Description Setting
138 Primary # Input Channel 1 Active Event Code 1
139 Primary # Input Channel 2 Active Event Code F
140 Primary # Input Channel 3 Active Event Code 8
141 not used
142 Primary # Input Channel 1 Fault Event Code F
143 Primary # Input Channel 2 Fault Event Code F
144 Primary # Input Channel 3 Fault Event Code F
145 not used
146 Primary # Phone Line 1 Voltage Fault Event Code 6
147 Primary # Phone Line 2 Voltage Fault Event Code 6
148 Primary # Phone Number 1 Comm. Fault Event Code 6
149 Primary # Phone Number 2 Comm. Fault Event Code 6
150 Primary # System Off Normal Fault Code 6
151 Primary # Input Channel 1 Active Restoral Code E
152 Primary # Input Channel 2 Active Restoral Code E
153 Primary # Input Channel 3 Active Restoral Code E
154 not used
155 Primary # Input Channel 1 Fault Restoral Code D
156 Primary # Input Channel 2 Fault Restoral Code D
157 Primary # Input Channel 3 Fault Restoral Code D
158 not used
159 Primary # Phone Line 1 Restoral Code A
160 Primary # Phone Line 2 Restoral Code A
161 Primary # Phone Number 1 Restoral Code A
162 Primary # Phone Number 2 Restoral Code A
163 Primary # System Off Normal Restoral Code A
164 Primary # System Test Message 9
165 Primary # System Abnormal Test Message F
166 not used
167 not used
168 not used
169 not used
TABLE 3-2: 4+2 Standard and 4+2 Express Formats - Primary
Address Description Setting
