411 Communicator Document #50921 Rev. E 12/09/2008 P/N 50921:E 33
Program Mode
All 3+1, 4+1 and 4+2 Expanded Formats Secondary Central Station Event Codes
If 0, 2, 3, 4, 5, 6, 7, 8 ,9, B or D is entered for address 50, the following data is automatically programmed for the
Secondary Central Station phone number event codes. Enter '0' for the Setting to disable the report to the Central
Station.
Secondary Central Station Number Account Code (51 - 54)
The four locations at addresses 51 - 54 default to all '0's. Valid entries are 0 - 9 and A - F. The number of digits
entered must match the format selection. If programming '2, 3, 4 or 5' into address 50, enter three digits (one digit
each in locations 51, 52 and 53 - location 54 is ignored). If programming '0, 1, 6, 7, 8, 9, A, B, C, D or E' into
address 50, enter four digits (one each in locations 51, 52, 53 and 54).
Secondary Central Station Number 24 Hour Test Time (55 - 58)
Use military time when entering the 24 hour 'test' time. The 24 hour test report to phone number 1 takes up four
locations, from addresses 55 - 58. The default is 00:00 (12:00 midnight). The limits for each location are as fol-
lows (do not use values of A - F as entries):
55: enter 0, 1 or 2
56: enter 0 - 9
57: enter 0 - 5
58: enter 0 - 9
TABLE 3-6: All 3+1, 4+1 and 4+2 Expanded Formats - Secondary
Address Description Setting
202 Secondary # Input Channel 1 Active Event Code 1
203 Secondary # Input Channel 2 Active Event Code F
204 Secondary # Input Channel 3 Active Event Code 8
205 not used
206 Secondary # Input Channel 1 Fault Event Code F
207 Secondary # Input Channel 2 Fault Event Code F
208 Secondary # Input Channel 3 Fault Event Code F
209 not used
210 Secondary # Phone Line 1 Voltage Fault Event Code 6
211 Secondary # Phone Line 2 Voltage Fault Event Code 6
212 Secondary # Phone Number 1 Comm.Fault Event Code 6
213 Secondary # Phone Number 2 Comm. Fault Event Code 6
214 Secondary # System Off Normal Fault Code 6
215 Secondary # Input Channel 1 Active Restoral Code E
216 Secondary # Input Channel 2 Active Restoral Code E
217 Secondary # Input Channel 3 Active Restoral Code E
218 not used
219 Secondary # Input Channel 1 Fault Restoral Code D
220 Secondary # Input Channel 2 Fault Restoral Code D
221 Secondary # Input Channel 3 Fault Restoral Code D
222 not used
223 Secondary # Phone Line 1 Restoral Code A
224 Secondary # Phone Line 2 Restoral Code A
225 Secondary # Phone Number 1 Restoral Code A
226 Secondary # Phone Number 2 Restoral Code A
227 Secondary # System Off Normal Restoral Code A
228 Secondary # System Test Message 9
229 Secondary # System Abnormal Test Message F
230 not used
231 not used
232 not used
233 not used
