Fire-Lite 411 - Format Selection Addresses ( 20 and 50) Programming

411 Communicator Document #50921 Rev. E 12/09/2008 P/N 50921:E 39
Central Station Communications
The digital communicator is capable of reporting detailed messages depending upon the Format in use. Table 4-1
shows the data reporting structure for each of the pulsed formats as well as the Ademco Express Formats. Ademco
Express Formats allow a typical data message to be transmitted to the Central Station in under 5 seconds. Pulsed for-
mats typically require 15 to 20 seconds in comparison. Table 4-2 defines each letter code used in Table 4-1 . See
“Ademco Contact ID Format Event Code Description” on page 42 for a description of the data reporting structure for
Ademco Contact ID Format.
TABLE 4-1: Format Selection Addresses ( 20 and 50) Programming
Format #
0, 2, 4, 6, 8
Format #
3, 5, 7, 9
Format #
1, A, C
Format #
B, D
Report
3+1/4+1/Standard
4+1 Express
3+1/4+1/Expanded
4+2/Standard 4+2
Express
4+2/Expanded
Fire Alarm SSS(S) FA
SSS(S) FA
FAFAFA(FA) 2
SSSS FAFA2 SSSS FAZ
Fire Alarm Restore SSS(S) RFA
SSS(S) RFA
RFARFARFA (RFA) 2
SSSS RFARFA2 SSSS RFAZ
Channel/Input Trouble
(Channel/Input Open)
SSS(S) TZ
SSS(S) TZ
TZTZTZ(TZ) Z
SSSS TZTZ2 SSSS TZZ
Channel/Input Trouble
Restore
SSS(S) RTZ
SSS(S) RTZ
RTZRTZRTZ(RTZ) Z
SSSS RTZRTZ2 SSSS RTZZ
System Trouble SSS(S) TS
SSS(S) TS
TSTSTS(TS) Y
SSSS TSTS2 SSSS TSY
System Trouble Restore SSS(S) RTS
SSS(S) RTS
RTSRTSRTS(RTS) Y
SSSS RTSRTS2 SSSS RTSY
AC Loss SSS(S) P
SSS(S) P
PPP(P) Z
SSSS PP2 SSSS PP2
AC Loss Restore SSS(S) RP
SSS(S) RP
RPRPRP(RP) Z
SSSS RPRP2 SSSS RPRP2
Fire Supervisory Condition SSS(S) V
SSS(S) V
VVV(V) Z
SSSS VV2 SSSS VZ
Fire Supervisory Condition
Restore
SSS(S) RV
SSS(S) RV
RVRVR(RV) Z
SSSS RVRV2 SSSS RVZ
Test Report SSS(S) X SSS(S) X SSSS XX2 SSSS XX2
