Fire-Lite 411 - 4+2 Standard and 4+2 Express Formats - Secondary

Program Mode
32
411 Communicator Document #50921 Rev. E 12/09/2008 P/N 50921:E
4+2 Standard and 4+2 Express Formats Secondary Central Station Event Codes
If 1, A or C is entered for address 50, the following data is automatically programmed for the Secondary Central Sta-
tion phone number event codes. Enter '00' for the Setting to disable the report to the Central Station.
214 - 216 Secondary # Input Channel 1 Fault Event Code 380 001
217 - 219 Secondary # Input Channel 2 Fault Event Code 380 002
220 - 222 Secondary # Input Channel 3 Fault Event Code 380 003
223 - 225 not used
226 - 228 Secondary # Phone Line 1 Voltage Fault Event Code 351 000
229 - 231 Secondary # Phone Line 2 Voltage Fault Event Code 352 000
232 - 234 Secondary # Phone Number 1 Comm. Fault Event Code 354 001
235 - 237 Secondary # Phone Number 2 Comm. Fault Event Code 354 002
238 - 240 Secondary # System Off Normal Fault Code 308 000
241 - 243 Secondary # System Test Message 602 000
244 - 246 Secondary # System Abnormal Test Message 608 000
247 - 249 not used
250 - 252 not used
253 - 255 not used
256 - 258 not used
TABLE 3-5: 4+2 Standard and 4+2 Express Formats - Secondary
Address Description Setting
202 - 203 Secondary # Input Channel 1 Active Event Code 11
204 - 205 Secondary # Input Channel 2 Active Event Code FF
206 - 207 Secondary # Input Channel 3 Active Event Code 83
208 - 209 not used
210 - 211 Secondary # Input Channel 1 Fault Event Code F1
212 - 213 Secondary # Input Channel 2 Fault Event Code F2
214 - 215 Secondary # Input Channel 3 Fault Event Code F3
216 - 217 not used
218 - 219 Secondary # Phone Line 1 Voltage Fault Event Code 64
220 - 221 Secondary # Phone Line 2 Voltage Fault Event Code 65
222 - 223 Secondary # Phone Number 1 Comm. Fault Event Code 6A
224 - 225 Secondary # Phone Number 2 Comm. Fault Event Code 6B
226 - 227 Secondary # System Off Normal Fault Code 6F
228 - 229 Secondary # Input Channel 1 Active Restoral Code E1
230 - 231 Secondary # Input Channel 2 Active Restoral Code E2
232 - 233 Secondary # Input Channel 3 Active Restoral Code E3
234 - 235 not used
236 - 237 Secondary # Input Channel 1 Fault Restoral Code D1
238 - 239 Secondary # Input Channel 2 Fault Restoral Code D2
240 - 241 Secondary # Input Channel 3 Fault Restoral Code D3
242 - 243 not used
244 - 245 Secondary # Phone Line 1 Restoral Code A4
246 - 247 Secondary # Phone Line 2 Restoral Code A5
248 - 249 Secondary # Phone Number 1 Restoral Code AA
250 - 251 Secondary # Phone Number 2 Restoral Code AB
252 - 253 Secondary # System Off Normal Restoral Code AF
254 - 255 Secondary # System Test Message 99
256 - 257 Secondary # System Abnormal Test Message 91
258 - 259 not used
260 - 261 not used
262 - 263 not used
264 - 265 not used
TABLE 3-4: Ademco Contact ID Format - Secondary
Address Description Setting
Channel/
Input #
