FISCHBEINCOMPANY
The Leader in Bag Closing Technology
REF : 14810F-GB
ED.A10/2001
14
Sticking particles must be removed by using a small brush .
Do not forget to clean arround the bottom of the machine , especially
around the looper and the knives .
If you are working in a very dusty environment , we recommend this
cleaning operation twice a day . To do that , simply slide open the looper
cover (11102) . Blow out the inside with compressed air . Close the
looper cover and tighten the cover pivot screw (11108) if necessary .
By doing these operations daily , you will increase the life of your
machine .
WEEKLY MAINTENANCE .
WARNING!!!!
Always disconnect the machine from the electrical power
source before performing any maintenance or adjustment
Clean the machine weekly , for a few minutes in a cleaning oil bath .
How to proceed ?
1. Fill in a small tank with cleaning oil
up to 6 cm maximum .
2. Remove looper cover located at the
bottom of the machine and the belt -
pulley cover and handle .
3. Plunge the machine vertically into
the oil so that it is immersed to the
level of the throat plate .
4. Turn the machine manually at the
pulley so the moving parts are
cleaned in the cleaning oil bath .
5. Remove the machine from the bath
and drain any excess of oil from the
mechanism .
6. Your machine is now free of dirt and parts are cleaned up .
7. If necessary you may want to loosen any stubborn dirt or grit with a small
brush and rinse the machine again .
