SCREWS AND HARDWARE .
All fasteners and hardware are assembled to Fischbein factory torque
specifications , but because of the vibration inherent in any machine
operation we recommend that periodic inspection and adjustment of
the following hardware items be performed to ward off potential
damage to the machine .
To proceed :
1. Unplug the machine .
2. Remove the needle guard (11101) and the looper cover (11102) .
3. Check the set screws on the needle bar clamp (40502) , and
tighten if necessary .
4. Check the set screw on the presser foot lifter (11652) , and
tighten if necassary .
5. Replace the needle guard (11101) .
6. Remove the looper cover (11102) .
7. Check the set screw and the clamp screw on the looper holder
(11301) , and tighten if necessary .
8. Check the socket cap screw holding the presser feet dog (11203)
and tighten if necessary .
9. Check the hex head screw on the knife bracket (11007) , and
tighten if necessary .
10. Replace the looper cover ( 11102) .
11. Remove the housing cover .
12. Check the set screws on the cam assembly (40310) , and tighten
if necessary .
13. Check the set screws on the connecting rod assembly (11079) , and
tighten if necessary .
WARNING!!! Never remove these screws or change the orientation of
either of these components . Never try to remove a broken
screw or attempt to drill it out .
Consult your repair center .
