FISCHBEIN F - Page 35

FISCHBEINCOMPANY
The Leader in Bag Closing Technology
REF : 14810F-GB
ED.A10/2001
35
PLATE B : MAIN SHAFT AND LOOPER ASSEMBLY .
Item . Qty. Part number . Description :
1 1 11600 Main shaft
1 11616 Collar , main shaft (only for model FB)
1 SC 54038 Soc. cap screw # 5-40 x 3/8
3 1 10420 Ring “O”
4 3 11006 Washer trust
5 1 11441 Bushing , main shaft rear
6 1 11079 Assembly connecting rod & eccentric (replacement)
7 1 40310 Assy. cam looper
1 SS 83212CP ** Soc.set screw # 8-32 x 1/2 cone point
1 SS 83212 ** Soc.set screw # 8-32 x 1/2
8 1 WIT 516 Washer , internal tooth
9 1 11608 Nut , hex special
10 1 11607 Bearing , rod end
11 1 40317 Assy , arm & stud cam follower
12 1 11308 Stud Cam follower
13 1 40307 Arm cam follower
14 2 SC 63258 Soc. cap screw # 6-32 x 5/8
15 2 40313 Washer flat
16 1 11309 Nut , hex special
17 1 67693 E-clips (1/4” shaft)
18 1 11303 Shaft looper
19 2 11445 Bushing , looper shaft
20 1 11301 Holder looper
1 SS 832316HD Soc.set screw # 8-32 x 3/16 HD
1 SC 54038 Soc.cap screw “ 5-40 x 3/8
21 1 11300 Looper
22 1 11447 Bushing main shaft , front
23 1 SB 83238 Soc .button screw # 8-32 x 3/8
24 1 WIT 8 Washer # 8 , internal tooth
25 1 11003 Clip angle
26 1 11437 Carrier block , feed dog
4 SS 64038FP Soc.set screw # 6-40 x 3/8 FP
27 1 11410 Washer felt
28 1 11446 Slide
29 1 11203 Feed dog
30 1 WS 8 Washer spring # 8
31 1 SC 8321 Soc. cap screw # 8-32 x 1
32 1 H 103238 Hex.screw # 10-32 x 3/8
33 1 WIT 10 Washer # 10 , internal tooth
34 1 11007 Bracket knife
35 1 11703 Knife , stationary
36 2 F 348516 Flat sunk screw # 3-48 x 5/16
37 1 11702 Knife , moving
38 2 F 348316 Flat sunk screw # 3-48 x 3/16
39 1 11016 Bushing , knife shaft
40 1 11707 Shaft knife
41 1 11704 Spring , knife tension
42 1 11125 Guard knife
43 1 SB 103214 Soc.button screw # 10-32 x 1/4
44 1 SB 83214 Soc. button screw # 8-32 x 1/4
** Max Torque: 0,14Nm
