FISCHBEINCOMPANY
The Leader in Bag Closing Technology
REF : 14810F-GB
ED.A10/2001
37
PLATE C: HANDLE AND ELECTRIC DRIVE
Item Qty. Part number Description .
1 1 11450 Assy. oil pump
2 1 11453 Plug , pump oil
3 1 SB 83212 Screw soc. Btn # 8-32 x 1/2
4 4 11472 Clamp , spring tubing
5 1 85128 Tubing oil pump Tygon ¼” OD (90mm long)
6 1 11479 Ring “ O “
7 1 SB 832114 Screw soc. Btn # 8-32 x 11/4
8 1 11475 Assy , valve block manifold
9 1 11478 Ring “ O “
10 1 85128 Tubing oil pump Tygon ¼” OD (153mm long)
11 1 11485 Weldment , manifold inside
12 1 11490 Fitting
13 1 SF 832516 Screw Soc.Flat # 8-32 x 5/16
14 2 PS 6.6x40
Spring Pin ¼” ∅ x1.5”
15 1 11198 Assy , guard
16 1 11909 Belt
17 1 11012 Hanger
18 1 11017 Clip , hanger
19 1 WIT 8 Washer , internal tooth # 8
20 1 NH 832 Nut # 8-32
21 1 11904 Pulley , assy
2 SS 103212 Soc.set screw # 10-32 x 1/2
22 2 SB 103212 Soc.button screw # 10-32 x ½”
23 1 11011 Cover , handle
24 1 SC 44034 Screw Soc. Cap # 4-40 x 3/4
25 1 12500 Switch
26 1 12427 Cord set
27 2 SC 142034 Soc.cap screw # 1/4-20 x 3/4
28 2 WS 14 Washer spring # 1/4
29 1 11028 Handle
30 1 11804 Bolt , thread clamping
31 10 SF 103238 Flat soc.screw # 10-32 x 3/8
32 1 11073 Strain relief
33 1 11902 Pulley motor
2 SS 832316 Soc.set screw # 8-32 x 3/16
34 1 67753 Motor 230 volt
34.1 12400-110V Motor 110 volt
34.2 12400-24V Motor 24 volt
34.3 67342 Motor 12 volt DC
35 1 11815 Stand , thread
36 1 11805 Wing nut
37 1 11906 Assy , hinge motor mount
38 2 11908 Screw , hinge
39 1 12428 Cord set reinforcement
40 1 11801 Guard pulley drive
41 1 11784 Adapter
42 2 B 83214 Binding screw # 8-32 x 1/4
43 2 WN 8 Washer nylon # 8
44 1 25010.. Thread cone
45 1 11084 Assy , belt guard and handle (items ,13..15,17...20,22..24,29)
