FISCHBEIN F - Motor Brushes

FISCHBEINCOMPANY
The Leader in Bag Closing Technology
REF : 14810F-GB
ED.A10/2001
39
PLATE D : MOTOR –230 Volt Ref: 67753
Item. Qty . Part number Description
1 2 67753-1 Screw, Housing set
2 2 67753-2 Washer, Housing set
3 2 67760 Screw, Cap-Brush holder
4 2 67761 Carbon Brush 6x8x15
5 2 67753-5 Screw, stop
6 2 67753-6 Holder Brush
7 1 67753-7 Housing Rear.
8 1 67753-8 Capacitor
9 2 67753-9 Bearing , ball 608ZZ
10 1 67753-10 Armature 230 V
11 1 67753-11 Washer Rubber
12 1 67753-12 Ring Rubber
13 2 67753-13 Screw , stator set
14 1 67753-14 Stator assy.,230Volt
15 1 67753-15 Insulation sleeve
16 2 67753-16 Nut
17 1 67753-17 Holder front (#10-32 MTG holes)
18 1 67753-18 Sealing nut cord glands
18-1 1 67753-18-1 Claw cord glands
18-2 1 67753-18-2 Seal cord glands
18-3 1 67753-18-3 Body cord glands
19 1 67753-19 Cord , motor 230V
Wire 1mm cross section cord length 407mm
