Instruction Manual
D103409X012
Parts
May 2013
114
Kit Description Part Number
10* Feedback Array Kit, Aluminum
Sliding Stem (Linear)
[kit contains feedback array and hex socket cap screws, qty. 2,
with hex key and alignment template. 210 mm (8-1/4 inch) kit
also contains insert]. Stainless steel kits only for use with
stainless steel mounting kits.
7 mm (1/4-inch)
Aluminum GG20240X012
19 mm (3/4-inch)
Aluminum GG20240X022
Stainless steel GG13199X012
25 mm (1-inch)
Aluminum GG20240X032
Stainless steel GG13199X022
38 mm (1-1/2 inch)
Aluminum GG20240X042
Stainless steel GG13199X032
50 mm (2-inch)
Aluminum GG20240X052
Stainless steel GG13199X042
100 mm (4-inch)
Aluminum GG20240X062
Stainless steel GG13199X052
210 mm (8-1/4 inch)
Aluminum GG20243X012
Stainless steel GG13199X072
Rotary
[kit contains feedback assembly, pointer, and travel indicator
scale]. Stainless steel kits only for use with stainless steel
mounting kits.
Aluminum GG10562X012
Stainless steel GG10562X022
Parts List
Note
Part numbers are shown for recommended spares only. For part
numbers not shown, contact your Emerson Process Management sales
office.
Parts with footnote numbers shown are available in parts kits; see
footnote information at the bottom of the page.
Key Description
Housing (see figure 8‐2 and 8‐4)
DVC6200 and DVC6205
1 Housing
(7)
11 Drive Screw (2 req'd) (DVC6205 only)
20 Shield (DVC6205 only)
52 Vent, plastic
(2)
74 Mounting Bracket (DVC6205 only)
Key Description Part Number
248 Screw, hex head (4 req’d) (DVC6205 only)
249 Screw, hex head (4 req’d) (DVC6205 only)
250 Spacer (4 req’d) (DVC6205 only)
267 Standoff (2 req’d) (DVC6205 only)
271 Screen
(7)
287 Gasket, Housing A only (used for GX actuator) (DVC6200 only)
288 Seal, Housing A only (used for GX actuator) (DVC6200 only)
Common Parts
(see figure 8‐2, 8‐3, and 8‐4)
DVC6200 and DVC6205
16* O‐ring
(1)
(3 req'd)
29 Warning label, for use only with LCIE hazardous area
classifications
33 Mach Screw, pan head, SST
(2)
(3 req'd)
38 Cap Screw, hex socket, SST
(2)(6)
(3 req'd)
43* Cover Assembly (includes cover screws)
Standard 38B9580X022
Extreme temperature option
(fluorosilicone elastomers) 38B9580X032
48 Nameplate
49 Screw, self tapping (2 req'd)
(6)
61 Pipe Plug, hex socket
(6)
Housing A with relay C (2 req'd ) (used for GX actuator)
Housing A with relay B (1 req'd) (used for GX actuator)
Housing B with relay B and C (1 req'd)
(used for all actuators except GX)
Not required for relay A
63 Lithium grease (not furnished with the instrument)
64 Zinc based anti‐seize compound (not furnished with the
instrument)
65 Lubricant, silicone sealant (not furnished with the instrument)
154 Retaining Ring
(2)
(3 req'd)
236 Screen (required for relay B and C only)
(7)
237 Module Base Seal
(1)
Module Base
(see figure 8‐2 and 8‐4)
DVC6200 and DVC6205
2 Module Base
(6)
11 Drive Screw
(6)
(2 req'd)
12 O‐ring
(1)
19 Shield
(6)
61 Pipe Plug, hex socket
(6)
(3 req'd)
243 Slotted Pin (flame arrestor)
(6)
(3 req'd)
*Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
6. Available in the Spare Module Base Assembly Kit
7. Available in the Spare Housing Assembly Kit
