Instruction Manual
D103409X012
Parts
May 2013
116
Key Description
PWB Assembly
(see figure 8‐2 and 8‐4)
DVC6200 and DVC6205
Note
Contact your Emerson Process Management sales office for PWB
Assembly FS numbers.
50* PWB Assembly
Standard
For instrument level AC
For instrument level HC
For instrument level AD
For instrument level PD
For instrument level ODV
Extreme Temperature option (fluorosilicone elastomers)
For instrument level AC
For instrument level HC
For instrument level AD
For instrument level PD
For instrument level ODV
Key Description Part Number
Pressure Gauges, Pipe Plugs, or
Tire Valve Assemblies
(see figure 8‐3)
DVC6200 and DVC6205
47* Pressure Gauge, nickel‐plated brass case, brass connection
Double‐acting (3 req'd); Single‐acting (2 req'd)
PSI/MPA Gauge Scale
To 60 PSI, 0.4 MPa 18B7713X042
To 160 PSI, 1.1 MPa 18B7713X022
PSI/bar Gauge Scale
To 60 PSI, 4 bar 18B7713X032
To 160 PSI, 11 bar 18B7713X012
PSI/KG/CM
2
Gauge Scale
To 60 PSI, 4 KG/CM
2
18B7713X072
To 160 PSI, 11 KG/CM
2
18B7713X082
66 Pipe Plug, hex head
For double‐acting and single‐acting direct w/gauges
(none req'd)
For single‐acting reverse w/gauges (1 req'd)
For all units w/o gauges (3 req'd)
67 Tire Valve, used with Tire Valve Option only
Double‐acting (3 req'd); Single‐acting (2 req'd)
HART Filters
HF340, DIN rail mount 39B5411X022
HF341, DIN rail Mount, pass through (no filter) 39B5412X012
*Recommended spare parts
