Fisher FIELDVUE DVC6200 User Manual

Instruction Manual
D103409X012
Detailed Setup
May 2013
47
Section 4 Detailed Setup
Detailed Setup44
Field Communicator Configure > Detailed Setup (1‐2)
Note
Detailed Setup is available for instrument level HC, AD, PD, and ODV.
Detailed Setup allows you to configure the digital valve controller to your application. Table 4‐1 lists the default settings
for a standard factory configuration. You can adjust actuator response, set the various modes, alerts, ranges, travel
cutoffs and limits. You can also restart the instrument and set the protection.
Table 4‐1. Default Detailed Setup Parameters
Setup Parameter Default Setting
(1)
Instrument
Configuration
Control Mode Analog
Restart Control Mode Resume Last
Zero Power Condition Valve Open
(2)
Analog In Range Low 4 mA
Analog In Range High 20 mA
Analog Input Units mA
Feedback Connection Rotary - All
(2)
Travel Sensor Motion CW/To Bottom Inst.
(2)
Auxiliary Terminal Action Disabled
Max Supply Pressure 20
(2)
Pressure Units PSI
(3)
Temperature Units F
(3)
Polling Address 0
Burst Mode Enable No
Burst Command 3
Cmd 3 Configured Pressure A-B
Dynamic Response and
Tuning
Tuning Set F
(2)
Input Characterization Linear
Travel Limit High 125%
Travel Limit Low -25%
Travel/Pressure Cutoff High 99.46%
Travel/Pressure Cutoff Low 0.50%
Set Point Rate Open 0%/sec
Set Point Rate Close 0%/sec
Set Point Filter Time (Lag Time) 0 sec
Integrator Enable Yes
Integral Gain 9.4 repeats/minute
Integral Deadzone 0.26%
-continued on next page-
