Instruction Manual
D103409X012
Parts
May 2013
121
Figure 8‐4. FIELDVUE DVC6205 Base Unit Housing Assembly (continued)
WALL MOUNTING
PIPE MOUNTING
GE40181
APPLY LUBRICANT, SEALANT, OR THREAD LOCK
APPLY LUBRICANT ON ALL O-RINGS UNLESS OTHERWISE SPECIFIED
