Instruction Manual
D103409X012
Installation
May 2013
15
Figure 2‐4. FIELDVUE DVC6205 Base Unit with Mounting Bracket (Rear View)
10C1796‐A
57
(2.25)
72
(2.82)
2 MOUNTING
HOLES
8.6 (0.34)
MM
(INCH)
Figure 2‐5. FIELDVUE DVC6205 Base Unit Wall Mounting
1‐INCH 1/4‐20
HEX HEAD
SCREW
SPACER
MOUNTING BRACKET
X0428
