FJDynamics AT2 Auto Steer System Hardware Installation Manual
11
GNSS
receiver
GNSS receiver 1
12 GNSS receiver bracket 1
13
Small self-
sealing bag
1
3M sticker 2
Fix the GNSS receiver
and bracket.
14
Assembly bolt
M4×12
4
15
Small self-
sealing bag
2
Self drilling screw 4
16
Nameplate
bracket
Nameplate bracket 1
With the nameplate
mounted.
17
Small self-
sealing bag
Hexagon socket
head cap screw
M6×16
2
Fix the nameplate
bracket.
18 Spring washer M6 2
19 Plain washer M6 2
20
Wiring
harnesses
Power wiring harness 1
21 GNSS receiver wiring harness 1
22 Main wiring harness 1
23 Spare main wiring harness 1
24 Attitude sensor wiring harness 1
25
Radio
antenna
Sucker base 1
26 Radio antenna 1
27 3M sticker 1 Fix the radio antenna.
28
Others
Large self-
sealing bag
Packing list 1
29 Warranty card 1
30
Software user
manual
1
31
Hardware
installation
manual
1
32 Certication 1
33 Nylon cable tie 20
