FJDynamics AT2 Auto Steer System Hardware Installation Manual
4.4 Installing the Radio Antenna
4.4.1 Components
4.4.2 Installation Steps
No. Name Qty. Remarks
1 Radio antenna 1
2 Sucker base 1
3 3M sticker 1
•
If there is no suitable metal plane on top of the machine, select and clean a suitable
plane to install the antenna. Attach the 3M sticker on the sucker base of the radio antenna,
and attach the antenna to the selected position.
