FJDynamics AT2 Auto Steer System Hardware Installation Manual
•
If there is a suitable metal plane on top of the machine, wipe the plane clean, and then
directly suck the radio antenna to the plane.
4.5 Installing the Control Terminal
4.5.1 Components
No. Name Qty. Remarks
1 Control terminal 1
2 Control terminal bracket 1
3
Control terminal mounting
base
1
Provided together with the
control terminal bracket4 Nut 4
5 U-bolt 2
