FJDynamics AT2 Auto Steer System Hardware Installation Manual
Note
: The splined sleeves, motor bracket, and attitude sensor bracket are not
included in the list and will be provided by the dealer separately. The dealer will
be responsible for the installation of such parts based on your machine model.
Above is the general shipping conguration. The actual shipment is subject to the contract
and may differ slightly. Check the items in the package according to the packing list or the
contract. If there is any doubt or discrepancy, contact your dealer.
Read Chapter 2 carefully, and ensure all requirements specied in this chapter are met
before installation.
Before installation, make a detailed plan and arrangement regarding the installation
position, power supply, and wiring of the equipment, and ensure that:
•
There is sufcient space to facilitate equipment installation and heat dissipation.
•
The environmental temperature and humidity meet the requirements.
•
The power supply and wiring meet the requirements.
•
The selected power supply matches the system power.
•
For a user-specic equipment, ensure that the specic requirements are met.
•
Cut off the power supply when installing the equipment.
•
Place the equipment in a dry environment.
•
Do not place the equipment in a high-temperature environment.
•
Keep the equipment away from high-voltage cables.
•
Keep the equipment away from strong thunderstorms and electric elds.
•
Unplug the power supply before cleaning.
•
Do not clean the equipment with liquids.
•
Do not open the equipment enclosure.
•
Fix the equipment rmly.
3 Inspection
3.1 Inspection Before Installation
3.2 Precautions
