5.2 Power-on
5.3 Parameter Calibration
1. Check whether the power supply is connected correctly.
2. Check whether the supply voltage is satisfactory.
1. Check whether the power indicator of the control terminal is lit.
2. Turn on the control terminal, and check whether the system program starts normally.
For details, refer to the
FJDynamics AT2 Auto Steer System Software User Manual.
5.2.1 Inspection Before Power-on
5.2.2 Inspection After Power-on
6 Appendix
6.1 Specications
No. Component Specications
1 Control terminal
Size: 275×180×40 mm
Basic conguration: 10.1-inch capacitive touch
screen, LED backlight, 1280×800 pixels, 700 nit
LCD, speaker, 2G RAM, 8G ROM;
Various communication interfaces;
Power supply: 9 V – 36 V
Signals received: radio, satellite, and 4G
Relative humidity: 0% – 95%, at 40°C (non-
condensing)
Wi-Fi: 2.4 GHz frequency band, frequency range:
2412 MHz – 2484 MHz, output power: 2.4 GHz 11 n
14±2 dBm
Operating temperature: -20°C to 70°C
Storage temperature: -40°C to 85°C
IP rating: IP65
