FJDynamics AT2 Auto Steer System Hardware Installation Manual
*Example 3: Installing with self drilling screws and 3M stickers
1 2
*Example 1: Installing with self drilling screws
*Example 2: Installing with 3M stickers
1
2. Install the GNSS receiver and bracket at the top of the machine where it is rm and has
low vibration by any of the following methods: 1. self drilling screw; 2. 3M sticker; and 3. self
drilling screw + 3M sticker.
