Hardware Installation Manual for FJD 3D Excavator Guidance System
7
Copyright © FJ Dynamics Technology Co., Ltd. All Rights Reserved.
8
Protective cover for
sensors
2
9
Hexagon socket head cap
screw M5×12
9
10
Hexagon socket head cap
screw M10×25
9
11
Pan head bolt with elastic
flat washer M6×14
13
12 Hexagon Nut Class 1 M4 18
13 Standard Spring Washer
φ10
9
14 Flat Washer
φ12
9
15 Attitude sensor harness 1
16 Power harness 1
17 Smart main harness 1
18
Adapter bracket of control
terminal
1
19 RTK bracket 2
20
RTK bracket antenna
mount
2
21 Antenna convertor 2
22
3M VHB double-
sided
tape
4
23 Nylon Strap Several
The items listed above are delivered in general cases. The delivered items may slightly differ
depending on the order contract. Please check the cargoes carefully in accordance with the packing
list or the order contract. Please contact our dealers if any questions or mistakes.
3. Installation
