Manual Flamcomat MK-U G4
We reserve the right to change designs and technical specifications of our products.
27
ENG
Error 401
Pump 1 Defect
Contact Installer
∑ 200 L
2.2 bar
12 %
Ext
Settings
Manual mode
Log in
Service info
2.2 bar
12%
12%
2.2 bar
High pressure alarm
Pset+
Pset
Pset-
Low pressure alarm
2,0 bar
6,0 bar
2,2 bar
1,8 bar
0,6 bar
12%
2.2 bar
Maintance 1
Maintance 2
Maintance 3
Maintance 4
11-11-2018
11-11-2018
11-11-2018
11-11-2018
Operation screen Menu screen Settings screen Read only screen
Operation Screen
Error 401
Pump 1 Defect
Contact Installer
∑ 200 L
2.2 bar
12 %
Ext
1
Screen icon
2
Node number
3
Advanced settings unlocked (login)
4
Current System Pressure
5
Current vessel level
6
Refill
7
System diagram
8
Pressure Release Valve
9
Compressor
Vessel
12%
2.2 bar
High pressure alarm
Pset+
Pset
Pset-
Low pressure alarm
2,0 bar
6,0 bar
2,2 bar
1,8 bar
0,6 bar
1
High pressure alarm
2
Upper operating pressure tollerance
3
Operating pressure
4
Lower operating pressure tollerance
5
Low pressure alarm
12%
2.2 bar
Upper level limit
Refill Stop
Refill Start
Minimal level
Low level limit
9 %
96 %
12 %
6 %
5 %
1
Upper level limit
2
Refill Stop
3
Refill start
4
Minimal level
5
Low level limit
6

8
9
Maximal Refill time per cycle
Maximum Refill litters per cycle
Refill interval
Refill cycles per day
Unlock advanced settings (login)
