Appendix 2. Technical data, specifications, hydraulic equipment
Operational values, volumes and dimensions
Nominal
volume
[Litres]
Maximum working
pressure
[bar]
Maximum
working
tempera-
ture
[°C]
Maximum
working
tempera-
ture
[°C]
Vessel
diameter
D
[mm]
Display
height
H1
[mm]
Height
H2*
[mm
Width
B
(mm)
Length
L2
[mm]
System
connec-
tion
S
[Inches]
MK-U MK
400 6 10 120 70 790 1065 1423 1015 860 225 G 1-1/4 Male
600 6 10 120 70 790 1485 1783 1015 860 225 G 1-1/4 Male
800 6 10 120 70 790 1585 2130 1015 860 225 G 1-1/4 Male
1000 6 10 120 70 790 1585 2479 1015 860 225 G 1-1/4 Male
1200 6 - 120 70 1000 1615 2100 1225 1070 100 G 1-1/2 male
1200 - 10 120 70 1000 1615 2150 2400 1070 100 R 1-1/2
1600 6 - 120 70 1000 1615 2600 1225 1070 100 G 1-1/2 male
1600 - 10 120 70 1000 1615 2650 3000 1070 100 R 1-1/2
2000 6 - 120 70 1200 1635 2350 1425 1270 0 R 2
2000 - 10 120 70 1200 1635 2400 1425 1270 0 R 2
2800 6 - 120 70 1200 1635 2950 1425 1270 0 R 2-1/2''
2800 - 10 120 70 1200 1635 3000 1425 1270 0 R 2-1/2''
3500 6 - 120 70 1200 1635 3750 1425 1270 0 R 2-1/2''
3500 - 10 120 70 1200 1635 3800 1425 1270 0 R 2-1/2''
5000 3 - 90 70 1500 1600 3600 1765 1615 625 Rp 1-1/2''
6500 3 - 90 70 1800 1600 3500 2070 1920 475 Rp 1-1/2''
8000 3 - 90 70 1900 1600 3550 2170 2020 425 Rp 1-1/2''
10000 3 - 90 70 2000 1600 3950 2270 2120 375 Rp 1-1/2''
* H2 with Flexvent Super = H2 + 85 mm
Dry weight of complete equipment [kg]
Nominal
volume
MK-U MK
K11 - K31 ** K40 **
Table value
+ 12 kg
Table value
+ 25 kg ***
[Litres] 3 bar 6 bar 10 bar 3 bar 6 bar 10 bar 3 bar 6 bar 10 bar
400 - 90 117 - 166 201 - 77 104
600 - 105 140 - 196 241 - 92 127
800 - 120 165 - 231 271 - 107 152
1000 - 135 190 - 266 321 - 122 177
1200 - 313 418 - 326 431 - 290 395
1600 - 368 508 - 381 521 - 345 485
2000 - 453 618 - 466 631 - 430 595
2800 - 538 758 - 551 771 - 515 735
3500 - 648 938 - 661 951 - 625 915
5000 976 - - - - - 953 - -
6500 1476 - - - - - 1453 - -
8000 1581 - - - - - 1558 - -
10000 1821 - - - - - 1798 - -
