FlashCut CNC Section 2 Stepper CNC Controller
12
The mating motor cable connector is a Molex - Waldom 6-Pin Mini-Fit Jr. Receptacle Housing
Part # 39-01-2060 with Female Pins Part # 39-00-0039 or 39-00-0047. Please see the section on
Stepper Motor Cabling later in this manual for more information.
Never connect or disconnect motor cables while the power
is on. This will result in damage to the driver box.
