FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 94 of 170
Application Weighing
The key is used to access the setpoint entry menu. Additionally, one of the function keys can be
programmed to access setpoint entry menu easily for frequent usage.
Entry the limit values at basic weighing
1. Press the key.
2. The setpoint 1 value appears on the display after the weight value is shown [ SP 1 1250 kg ].
3. Enter the new value by numerical keys. You may press key to enter negative limit value. Press
the key to save it and to go to the next setpoint.
4. Repeat from step 2 for entering following setpoints.
5. FT-112(D) Panel returns to the operation after displaying setpoint 5 and entering its value,
6. Press key to return operation at any step.
In / Out
Weighing
Classifying
Checkweighing
Filling
Peak hold
Input 1
Parameter 351
Start
Start
Start
Start
Input 2
Parameter 352
Reset
Reset
Reset
Reset
Input 3
Parameter 353
Parameter 353
Parameter 353
Parameter 353
Parameter 353
Input 4
Parameter 354
Parameter 354
Parameter 354
Parameter 354
Parameter 354
Output 1
Parameter 361
− − Tolerance
− Tolerance
Ready
Ready
Output 2
Parameter 362
− − Tolerance
OK
Fine
Run
Output 3
Parameter 363
OK
+ Tolerance
Coarse
End of testing
Output 4
Parameter 364
+ + Tolerance
Parameter 364
End of Filling
Alarm
Output 5
Parameter 365
+ + Tolerance
Parameter 365
Parameter 365
Parameter 365
