FLIR E54 User Manual

Camera overview
6
1. Laser distance meter.
1
2. Infrared lens.
3. Focus ring.
4. Autofocus button.
1
5. Trigger.
6. Lamp for the digital camera (left and right sides).
7. Digital camera.
8. Attachment point for the hand strap bracket (left and right sides).
9. Tripod mount.
10. Attachment point for the hand strap, wrist strap, or lanyard strap (left and right sides).
#T810587; r. AD/90967/90989; en-US
12
1. This item is dependent on the camera model.

FLIR E54 Specifications

General

Resolution	320 x 240 pixels
Accuracy	±2°C (±3.6°F) or ±2% of reading
Field of View	24° × 18°
Focus	Manual
Digital Camera	5 MP
Laser Distance Meter	No
Image Modes	MSX, Picture-in-Picture
Connectivity	Wi-Fi, Bluetooth
Battery Life	4 hours
Storage Media	SD card
Weight	1 kg
Minimum Focus Distance	0.15 m
Spectral Range	7.5 – 14 µm
Operating Temperature Range	-15°C to 50°C
Storage Temperature Range	-40°C to 70°C
Thermal Sensitivity	< 0.04°C (40 mK)
