Working with measurement tools
13
13.1 General
To measure a temperature, you can use one or more measurement tools, e.g., a spot-
meter or a box.
13.2 Adding/removing measurement tools
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Measurement) and push the navigation pad. This displays a submenu.
3. Use the navigation pad to select one of the following:
• Select
(No measurements) to remove all tools.
• Select
(Center spot) to add a center spot.
• Select
(Hot spot) to add a hot spot detection within a box area.
• Select
(Cold spot) to add a cold spot detection within a box area.
• Select (depending on the camera model)
(User preset 1) to add user preset 1
or (3 spots) to add three spots.
• Select (depending on the camera model)
(User preset 2) to add user preset 2
or
(Hot spot - Spot) to add a hot spot and a spot and display the temperature
difference.
4. Push the navigation pad to confirm and exit the menu mode.
13.3 Editing user presets
Note The availability of this feature is dependent on the camera model.
A user preset is a measurement tool, or a group of measurement tools, with predefined
characteristics.
Follow this procedure:
1. Push the navigation pad to display the menu system.
#T810587; r. AD/90967/90989; en-US
79
