Technical data23
Laser pointer
Laser classification Class 2
Laser type Semiconductor AlGaInP diode laser
Laser power 1 mW
Laser wavelength 635 nm (red)
Data communication interfaces
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
Audio Microphone headset via Bluetooth for voice anno-
tation of images
USB
USB
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / un-
compressed colorized video
USB, standard USB Mini-B: 2.0
USB, connector type
• USB-A connector
• USB Mini-B connector
Composite video
Video out Composite
Video, standard CVBS (ITU-R-BT.470 PAL/SMPTE 170M NTSC)
Video, connector type 4-pole 3.5 mm jack
Radio
Wi-Fi
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
Bluetooth Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery voltage 3.7 V
Battery capacity
4.4 Ah, at +20°C to +25°C (+68°F to +77°F)
Battery operating time
Approx. 4 hours at +25°C (+77°F) ambient tem-
perature and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
2-bay charger
Charging time 4 h to 90% capacity, charging status indicated by
LED's
Charging temperature 0°C to +45°C (+32°F to +113°F)
Power management Automatic shutdown and sleep mode (user
selectable)
AC operation AC adapter, 90–260 VAC input, 12 V output to
camera
Start-up time from sleep mode Instant on
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
#T559845; r. AJ/37554/37554; en-US
