FLIR E60 User Manual

Technical data23
23.23 FLIR E63 (incl. Wi-Fi)
P/N: 64501-0402
Rev.: 35207
General description
The FLIR Exx series cameras are compact and rugged infrared cameras that can be used in harsh envi-
ronments while still providing you with the latest technology such as a modern touch screen and wire-
less connectivity. A FLIR Exx series camera is the perfect choice when you are looking for a robust but
feature-rich camera at an affordable price.
Benefits:
• Robust and sophisticated: The FLIR Exx series cameras have a robust and light-weight design and
can withstand a 2 m drop. Large buttons combined with a modern touch screen and extensive
measuring capabilities, they are the right choice for demanding inspections in the field.
• Easy communication: The Wi-Fi connectivity of the FLIR Exx series cameras allows you to connect
to smart phones and tablets, for the wireless transfer of images or the remote control of the camera.
The Bluetooth-based METERLiNK function transfers readings from external measurement instru-
ments to the infrared image.
• Best value for money: The FLIR Exx series cameras combine good performance (up to 320 × 240
pixels), a user-friendly interface, and a rugged point-and-shoot design with an affordable price.
Imaging and optical data
IR resolution 320 × 240 pixels
Thermal sensitivity/NETD < 0.05°C @ +30°C (+86°F) / 50 mK
Field of view (FOV)
25° × 19°
Minimum focus distance 0.4 m (1.31 ft.)
Focal length 18 mm (0.7 in.)
Spatial resolution (IFOV)
1.36 mrad
F-number 1.3
Image frequency 60 Hz
Focus Manual
Digital zoom 2× and 4×
Panning Panning over zoomed-in images
Detector data
Detector type Focal plane array (FPA), uncooled
microbolometer
Spectral range
7.5–13 µm
Image presentation
Display
Touch screen, 3.5 in. LCD, 320 × 240 pixels
Image adjustment Auto or manual
Image presentation modes
Image modes
IR image, visual image, MSX, picture in picture,
thumbnail gallery
Picture in Picture
Scalable IR area on visual image
Measurement
Object temperature range
• –20°C to +120°C (–4°F to +248°F)
• 0°C to +650°C (+32°F to +1202°F)
Accuracy ±2°C (±3.6°F) or ±2% of reading, for ambient tem-
perature 10°C to 35°C (+50°F to 95°F)
#T559845; r. AJ/37554/37554; en-US
120

FLIR E60 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	<0.05°C at 30°C
Field of View	25° x 19°
Battery Life	4 hours
Spatial Resolution	1.36 mrad
Image Frequency	60 Hz
MeterLink	Yes
Laser Pointer	Yes
Text Annotation	Yes
Storage Media	SD card
Spectral Range	7.5 – 13 µm
Temperature Range	-20°C to +650°C
Display	3.5" LCD touchscreen
Focus	Manual
Accuracy	±2°C or ±2% of reading
Image Modes	Thermal, visual, MSX
Voice Annotation	Yes
Battery Type	Li-Ion battery
Minimum Focus Distance	0.4 m
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Connectivity	Wi-Fi, USB
Image Storage	JPEG
