FLIR E60 User Manual

Handling the camera13
5. Rotate the lens 30° clockwise.
6. Turn on the camera.
7. Specify the lens under Settings > Add-on lens.
13.7 Calibrating the touchscreen
13.7.1 Figure
13.7.2 Procedure
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Use the navigation pad to go to Settings.
3. Push the navigation pad.
4. Select Device settings and push the navigation pad.
5. Select Setup camera and push the navigation pad.
6. Select Calibrate touchscreen and push the navigation pad.
7. Follow the on-screen instructions.
13.8 Using the camera lamp
13.8.1 General
The camera lamp can be used as a flash for the digital camera. When the flash function
is activated, the camera lamp will flash when an image is saved by pushing the Save
button.
The camera lamp can also be used as a flashlight.
#T559845; r. AJ/37554/37554; en-US
29

FLIR E60 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	<0.05°C at 30°C
Field of View	25° x 19°
Battery Life	4 hours
Spatial Resolution	1.36 mrad
Image Frequency	60 Hz
MeterLink	Yes
Laser Pointer	Yes
Text Annotation	Yes
Storage Media	SD card
Spectral Range	7.5 – 13 µm
Temperature Range	-20°C to +650°C
Display	3.5" LCD touchscreen
Focus	Manual
Accuracy	±2°C or ±2% of reading
Image Modes	Thermal, visual, MSX
Voice Annotation	Yes
Battery Type	Li-Ion battery
Minimum Focus Distance	0.4 m
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Connectivity	Wi-Fi, USB
Image Storage	JPEG
